MBM04 Location Relay Beacon
Stokda varSKU: 100528
0 ₼
Turn Vague Zones into Pinpoint Clarity with Decade-Long Power.
minew importrepeater
Sürətli Çatdırılma (1-3 gün)
1 il rəsmi zəmanət
100% orijinal məhsul
Pulsuz quraşdırılma
The MBM04 is a powerful, spatial-aware hub designed to deliver precise, cost-effective, and future-ready positioning for your operations. It acts as an Anchor, Relay, and Beacon, achieving high-accuracy tracking (1–3m) by forwarding data from up to 100 tags. Engineered for reliability, the MBM04 features a rugged IP67 design and a 10-year maintenance-free operation to eliminate labor costs and downtime. Its powerful relay functionality and ultra-low-power radio reduce gateway deployment by 50% while supporting Bluetooth 6.0 Channel Sounding for future upgrades. Simply place the MBM04 for instant wireless setup, making it the engine of growth for your spatial intelligence needs.
- 1–3 Meter Precision Tracking
- 3-in-1 Anchor, Relay & Beacon
- nRF54L15 Chipset
- Bluetooth Channel Sounding Ready
- Forwards Data from Up to 100 Tags
- 10-Year Battery Life
- IP67 Industrial-Grade Durability
- True Wire-Free Deployment
Xüsusiyyətlər
Spesifikasiyalar
Spesifikasiyalar
| Model | MBM04 |
| Batareya | 10,800mAh (Li-SOCl₂) |
| Service Life | 10 years |
| İşləmə temperaturu | -40°C ~ +80°C |
| Operating Humidity | 0% ~ 99% RH |
| Sensor | Akselerometr sensoru |
| Konfiqurasiya | MinewLink App or remote configuration |
| LED Indicator | RGB |
| Düymə | Power on / button alarm |
| Bluetooth Version | Bluetooth LE 6.1 |
| Broadcasting Power | 0dBm (-40dBm ~ +8dBm) |
| Data Transmission Rate | 1Mbps (125Kbps / 1Mbps) |
| Broadcast Range | 150m (standard) / 600m (long-range) in open field |
| Scanning Range | 100m (open field) |
* 600m long-range mode coming soon.
