LWC01 LoRaWAN Personnel Badge
In StockSKU: 100549
0 ₼
LWC01 LoRaWAN Personal Nişanı standart LoRaWAN protokolundan istifadə edən uzunmüddətli kadr yerləşdirmə nişanıdır. Bluetooth yerləşdirməni dəstəkləyir
minew importpersonnel-tag
Fast Delivery (1-3 days)
1 Year Official Warranty
100% Original Product
Free Installation
The LWC01 LoRaWAN Personnel Badge is a long-range personnel positioning badge utilizing the standard LoRaWAN protocol. It supports Bluetooth positioning technology and includes an integrated accelerometer, enabling real-time personnel location updates to the management platform. The smart badge features an SOS alarm button for emergency distress signals to ensure personnel receive prompt assistance. It is powered by a rechargeable lithium battery. With its compact size, straightforward functionality, and user-friendly design, the LWC01 smart badge can be deployed in various applications, including attendance management in schools and enterprises, visitor management, patrol inspections, and medical institutions.
- Standard LoRaWAN protocol
- Over 1km communication range (open areas)
- Bluetooth real-time positioning
- Built-in accelerometer
- SOS alarm button
- IP65 waterproof and dustproof
- Easy magnetic charging
- Compact & portable
How it works
loT Gateway & Cloud Server
The gateway uploads the data to the cloud server. The cloud server analyzes and processes the data to achieve asset and people management functions.
LWC01 Badge
The LWC01 badges collect the Bluetooth signals broadcast by the beacons and then forward the data to the LoRaWAN gateway.
Bluetooth Beacon
Beacons are reasonably pasted to walls or pillars. Beacons broadcast Bluetooth signals in real-time.
Real-time Location Visibility
Leveraging Bluetooth positioning technology and an embedded accelerometer, the LWC01 LoRaWAN Personnel Badge offers unparalleled accuracy in locating personnel, making it the ideal solution for mobile worker safety management.
Longer Communication Range
The LWC01 smart badge, utilizing the standard LoRaWAN protocol, offers reliable communication over distances exceeding 2 kilometers.
It guarantees a stable connection in expansive areas such as warehouses, factories, or other large-scale environments.
Low Power Consumption
Powered by a built-in rechargeable 900 mAh battery, the smart badge utilizing LoRaWAN technology operates for extended periods with low power usage.
Instant SOS Alarm
The LWC01 LoRaWAN® smart badge features a prominent SOS alarm button (available in customizable red or other colors & patterns). Upon activation, it promptly sounds a high-volume alarm locally and sends an alert to the remote management platform. This vital feature empowers users to request immediate assistance and to be quickly located during emergencies.
Dual Reporting Mode
In addition to reporting data every 30 minutes (adjustable), the LWC01 badge instantly sends a report when the built-in accelerometer sensor is triggered. This helps in real-time detection of any movement changes in personnel, such as falls, rapid movements, or sudden stops, enabling the quickest response to ensure their safety.
Lightweight, Handy, and Multi-purpose
The LWC01 smart badge is small enough to fit in your pocket or be worn around the neck with a lanyard. Despite its compact size, it offers a multitude of functionaliteis, including LED indicator, magnetic charging connector, and a buzzer with 70dB high volume. Housed in an IP65 water-resistant casing, it demonstrates durability even in harsh, dusty environments.
Applications of LWC01 LoRaWAN Personnel Badge
-
Patrol Management
By providing real-time locating and management of security patrol personnel, while simultaneously monitoring patrol routes and work progress, the LWC01 smart badge ensures the completion and documentation of all patrol tasks. -
Hospital & Healthcare
The LWC01 offers real-time location tracking for patients and healthcare staff, enhancing their safety within the hospital. By pressing the SOS emergency button, patients can swiftly alert the closest healthcare personnel, significantly reducing emergency response times. -
Attendance Management
By automatically recording information such as employee check-ins and check-outs, the LWC01 badge can streamline the attendance management and minimizes errors. It is effective in both enterprise and school settings. -
Worker Safety Tool
The LWC01 smart badge is ideal for monitoring workforce safety and security, especially in large, high-density environments like warehouses and construction sites. It provides real-time location of personnel, and the emergency SOS alarm button ensures immediate assistance in case of danger.
Specifications
| Basic Info. | |
|---|---|
| Shell Material | PC |
| Power Supply | Rechargeable lithium battery |
| Battery | 4.2V/900mAh (rechargeable) |
| Service Life | 9 days (report interval at 15 seconds) |
| Operating Temperature | -10℃ ~ 50℃ |
| Operating Humidity | 10% ~ 90% RH, non-condensing |
| Protection | IP65 |
| LoRaWAN Specs. | |
| Operating Frequency | Multiple bands optional: EU868/US915/AS923/KR923/IN865 etc |
| Communication Protocol | Standard LoRaWAN protocol |
| Operating Mode | Class A |
| Communication Distance | >1km (in open area) |
| Reporting | 30 minutes (adjustable), immediate reporting when triggered by ACC |
| Hardware Specs. | |
| Sensor | Accelerometer |
| Button | One button (Power on/off/SOS) |
| BLE Chip | nRF52 series |
| Bluetooth Transmitting Power | -10~0dBm |
| BLE Receiving Sensitivity | -96dBm |
