MST01 Pt100 Temperature Sensor
In StockSKU: 100554
0 ₼
MST01 Pt100 RTD Temperatur Sensoru sənaye IoT tətbiqləri üçün ideal olan dəqiq və etibarlı temperatur ölçmə təklif edir. Müxtəlif mühitlər üçün geniş ölçmə diapazonuna malik qida səviyyəli zond.
minew importsensor-tag
Fast Delivery (1-3 days)
1 Year Official Warranty
100% Original Product
Free Installation
MST01 Pt100 Temperature Sensor is a Bluetooth device designed for ultra-low and precise temperature monitoring and threshold alarms. It excels in high and low-temperature environments, making it ideal for industries like food, medical, vaccine, and biological sectors. The MST01 stands out with its customizable probes, offering flexibility to match different cable lengths and temperature ranges, ensuring it’s perfectly suited for any application. Crafted from food-grade materials, the MST01 is safe for use in sensitive environments, including food processing and storage. With 24/7 monitoring, users can set multiple custom temperature thresholds and receive instant alerts if any are breached. The sensor’s large local storage capacity ensures you won’t lose critical data, keeping your operations running smoothly.
Key Benefits: Designed for High-Performance Environments
Customizable Probes Various custom options are available, including FEP wire length, probe material and length, and temperature range.- Food-Grade ProbesMade from food-grade materials, the MST01 Pt100 temperature sensor is perfect for sensitive environments requiring strict hygiene standards.
- High-Precision MonitoringUtilizes a 4-wire Pt100 sensor with Class A accuracy for precise temperature measurements, along with a calibration report.
- Ultra-Low Temperature Capabilities The sensor supports extreme low-temperature monitoring, with different probes covering -40 ~ 180°C and -200 ~ 200°C* . The range can be customized as needed.
- Real-Time Data VisualizationDisplays stored data status, including max, min, and average values, and whether data is within thresholds. Temperature data can be visualized via an app and exported to Excel.
- Configurable Temperature ThresholdsUsers can set multiple temperature thresholds to receive immediate alerts when limits are exceeded, allowing for timely adjustments.
- Large Local Data Storage of 20,408 LogsCapable of storing up to 20,408 logs, ensuring comprehensive data collection and minimizing the risk of data loss.
- IP67 Dust and Water ResistanceBuilt to withstand harsh environments, the MST01 is fully protected against dust and water, making it ideal for industrial high-performance applications.
NIST Certified
Ensuring unwavering accuracy in the harshest environments, the MST01 sensor is rigorously tested and validated through NIST-traceable calibration.
Seamless Solutions for Diverse Scenarios
Ultra-low temperature storage technology is widely used in the medical and food industries. It provides more effective preservation of living tissues, biological samples or seafood, and ensures the freshness. Minew’s MST01 series can reach temperatures as low as -200°C, meeting the ultra-low temperature recording needs of various industries.
Biological Sample
Seafood Preservation
Laboratory Investigation
Medical Vaccine
Dry Ice Transportation
MST01 Series Comparison Table – Key Specifications Overview
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
| Version | MST01-01 | MST01-02 | MST01-03 | MST01-04 | MST01-09 | MST01-10 | MST01 LoRaWAN L01 | MST01 LoRaWAN L02 | MST01 LoRaWAN L03 |
| Features | Breathable Short Temp & Humidity Probe | PE Protective Cover, Dustproof and Antifogging, Short Temp & Humidity Probe | PE Protective Cover, Dustproof and Antifogging, Long Temp & Humidity Probe | Stainless Steel Long Temp & Humidity Probe | Pt100 Sensor, Ultra-low Temperature Detection, Class A Accuracy | Food-grade Probe, Class A Accuracy | LoRaWAN-based, nRF54L15 Chipset, 100,000 Data Loas |
||
| Body Material | ABS+PC | ||||||||
| Wire Material | / | PVC | FEP | / | |||||
| Size Main Body (L*W*H) |
75*66.5*27mm (without bracket) 82*66.5*31.3mm (with bracket) |
||||||||
| Size probe(D*H) | Φ15.5*48mm | Φ15*30.5mm | 1 m (probe + cable length) | 1.07 m (probe +cable length) | 1.15 m (probe +cable length) | Φ15*30.5mm | 1 m (probe + cable length) | ||
| Weight | 106.8g | 103.1g | 131.1g | 128.9g | 129g | 138g | 100g | 105g | 127g |
| Sensor | Digital humidity and temperature sensor | Pt100，4-Wire | Digital humidity and temperature sensor | ||||||
| Temperature Range | -30℃ ~ 70℃ | -30℃ ~ 80℃ | -40℃ ~ 125℃ | -200℃ ~ 200℃ | -40℃ ~ 180℃ | -30~70℃ | -45℃ ~ 125℃ | ||
| Temperature Accuracy | ±0.3℃ (0 ~ 30℃) ±0.5℃ (other ranges) |
±0.5℃ (-30 ~ 80℃) ±1℃ (other ranges) |
±0.5℃ (-70 ~ 130℃) ±1℃ (-130 ~ 180℃) ±2℃ (other ranges) |
±0.5℃ (-40 ~ 130℃) ±1℃ (other ranges) |
±0.3℃ (0~30℃) ±0.5℃ (other ranges) |
±0.5℃ (-10~50℃) ±1℃ (other ranges) |
|||
| Temperature Resolution | 0.01℃ | ||||||||
| Temperature Units | ℃ / ℉ | ||||||||
| Humidity Range | 0~100%RH | / | 0~100%RH | ||||||
| Humidity Accuracy | ±5%RH | / | ±5%RH | ||||||
| Humidity Resolution | 0.01%RH | / | 0.01%RH | ||||||
| Logging Capacity | 20,480 | 10,0000 | |||||||
| Recording Mode | Cyclic storage ( older data is automatically overwritten when capacity is full ) | / | |||||||
| Bluetooth Chipset | Nordic nRF52 series | Nordic nRF54L15 chipset | |||||||
| Protocol | Bluetooth LE 5.0 | LoRaWAN | |||||||
| Broadcast Power | -40dBm ~ +4dBm | 19dBm(max) | |||||||
| Broadcast Range | 200 m (open area) | 150 m (open area) | Communication distance: > 1km (Visual range) |
||||||
| Battery Capacity | 2,700 mAh ( lithium battery ) | ||||||||
| Battery Life | 3 years (default) | 10 years | 5 years | ||||||
| LCD Display | Supported | / | Supported | ||||||
| Buzzer | Supported | / | |||||||
| OTA | Supported | ||||||||
| Security | Supports password-protected connections to prevent unauthorized access and modifications. | ||||||||
| Operating Temperature | -30 ~ 70℃ | ||||||||
| Operating Humidity | 0~95%RH，no condensation | ||||||||
| Protection | IP65 | IP64 | IP65 | IP65 / IP67 | IP67 | IP64 | IP67 |
